Origin Acoustics A1250 - Amplifier Specifications; Amplifier Linedrawings

A1250 AMPLIFIER INSTALLATION USER MANUAL
3
2
A1250 AMPLIFIER INSTALLATION USER MANUAL

 
 
 50 Watts per Channel
 820 Watts
 @4Ω=0.9%/ @8Ω=1.0%
 600mV

10Hz - 20kHz
 85Hz - 20kHz /-3dB
 10Hz - 150Hz / -3dB
 -75dB
 5mV
 8min
 AC 230V / 50 Hz
AC 110V / 60 Hz
 17'' W (19'' including rack mounts)
1
3/4
'' H (2
1/8
'' including feet)
10'' D (front to rear chassis)
10
5/8
'' D (front to rear speaker phoenix connectors)
 9.1 lb
 TUV Listed and tested under UL/EN60065 for US and Canada
 
100-120 V ~ 60Hz / 220-240V ~ 50Hz 600W
FUSE T10AL / 250V
