Orion HCCA102 User Manual

4 ohm 4 oh 4
ohm
4 ohm
Parall
el—Two Speakers (dual 4 ohm voice coils)
Two dual
4 ohm voice coil woofers with voice coils in parallel and the two woofers in
parallel results in a 1 ohm load to the amplifier.
- - - -
+
+
+
+
+
Figu
re 5
-
Figur
a 5
Abbildung 5
1. Connec
t the speaker in parallel by connecting the four positive (+) terminals
together and the four negative (-) terminals together.
2. Wire the positive (+) terminals of the woofers to the positive (+) terminal on the
amplifier. Wire the negative (-) terminals of the woofers to the negative (-) terminal
on the amplifier.

Orion HCCA102 Specifications

General

Brand	Orion
Model	HCCA102
Category	Subwoofer
Language	English
