Orion XTRPRO122D User Manual

18
ENCLOSURE RECOMMENDATIONS
Enclosure Details
1. External dimensions calculated for 3/4” building material
2. Includes speaker displacement
3. Volumes given are net tuning volume
4. Enclosures include a minimal amount of damping material. Just enough material to
line the inside of the enclosure is required.
XTRPRO102 & 104 Sealed Enclosure Recommendations
Box Properties
— Description
—
Type:
Closed Box
Shape: Prism, Square
— Box Parameters —
Vb = 0.75
cu.ft
V(total) = 0.791 cu.ft
Qtc = 0.598
QL =
7
F3 = 50.61
Hz
Fill =
none
External Dimensions
A = 12 in. (305
mm)
B = 15.5 in. (394
mm)
C = 10.8 in. (274 mm)
Internal
Dimensions
A = 10.5 in. (267
mm)
A
B = 14 in. (356
mm)
C = 9.3 in. (236
mm)
C
Wall
Thickness
Front = 0.75 in. (19
mm)
B Side = 0.75 in. (19
mm)
c
To p
&
Bottom
b
d
Front &
a
Back
c
Sides
—Box
Parts—
Box Shape: Square
Prism
1Top,1
Bottom:
depth (c) = 10.8 in. (274
mm)
width (b) = 15.5 in. (394 mm)
thickness = 0.75 in. (19 mm)
1 Front, 1
Back:
height (a) = 10.5 in. (267
mm)
width (d) = 14 in. (356 mm)
thickness = 0.75 in. (19 mm)
2 Sides: height (a) = 10.5 in. (267
mm)
depth (c) = 10.8 in. (274 mm)
thickness = 0.75 in. (19 mm)
Figure 14
Figura
14
Abbildung
14
—Driver Mounting—
Mounting: Front
