Orion XTRPRO122D User Manual

20
XTRPRO122 & 124 Sealed Enclosure Recommendations
Box Properties
— Description
—
Typ e:
Closed Box
Shape: Prism, Square
— Box Parameters —
Vb = 1.5
cu.ft
V(total) = 1.55 cu.ft
Qtc = 0.717
QL =
6.886
F3 = 43.09
Hz
Fill =
none
External Dimensions
A = 16 in. (406
mm)
B = 16 in. (406 mm)
C = 14.24 in. (362
mm)
Internal Dimensions
A = 14.5 in. (368
mm)
A
B = 14.5 in. (368
mm)
C = 12.74 in. (324
mm)
C
Wall
Thickness
Front = 0.75 in. (19
mm)
B Side = 0.75 in. (19
mm)
c
To p
&
Bottom
b
d
Front &
a
Back
c
Sides
—Box
Parts—
Box Shape: Square
Prism
1Top,1
Bottom:
depth (c) = 14.24 in. (362 mm)
width (b) = 16 in. (406 mm)
thickness = 0.75 in. (19 mm)
1 Front, 1
Back:
height (a) = 14.5 in. (368
mm)
width (d) = 14.5. (368 mm)
thickness = 0.75 in. (19 mm)
2
Sides:
height (a) = 14.5 in. (368
mm)
depth (c) = 14.24 in. (362 mm)
thickness = 0.75 in. (19 mm)
Figure 16
Figura
16
Abbildung
16
—Driver Mounting—
Mounting: Front
