8. General terms and conditions
Orlaco Products BV is not liable for damage resulting from inadequate servicing,
incorrect usage or alterations made to the equipment without informing the
manufacturer in writing.
This installation manual has been made available by Orlaco Products BV.
All rights reserved. No part of this manual may be reproduced and/or made
public in printed form, in photocopy form or on microfilm, or in any other way,
without the prior written permission of Orlaco. This also applies to the associa-
ted drawings and figures.
Orlaco reserves the right to make changes to components at any time without
informing customers beforehand or directly. All dimensions given are for com-
mercial purposes.
For information regarding repairs that is not covered in this manual, please
contact the Orlaco Products BV service department.
This manual has been prepared with all due care and attention. However, Orlaco
Products BV cannot be held responsible for any errors in this manual or any
consequences thereof.
9. Revision details
R1-0. First issue, November 2015.
R1-1. Added torque chapter 1, December 2015.
R1-2. Specifications: weight changed, March 2016.
R1-3. Specifications: compression Camera EMOS changed, August 2016.
A 01. Vertical lens angles added, March 2017.
A 02. Color of camera cable wiring changed, page 6; July 2017.
A 03. Camera EMOS BroadR-Reach added; January 2018.
A 04. Specs; ingress protection changed; January 2018.
A 05. Specs; EMOS Protocols PTP + gPTP deleted; June 2018.
1.1. Camera attachment 4
2. Pin connection 6
3. Specifications HMOS 8
4. Specifications EMOS Ethernet 11
5. Specifications EMOS BroadR-Reach 14
7. Disposal 17
8. General terms and conditions 18
9. Revision details 18
