IM0973570 A 05
12
Installation manual
Image processing: Color and gamma correction, 3D noise correction, edge
enhancement, digital WDR, advanced contrast enhancement, auto white-balance,
auto exposure control, mirroring, flipping, photometric and geometric lens
distortion correction.
Electrical
Power input: 12/24V/DC. Below 7V: camera is non-functional. Above 33V the
overvoltage protection is activated. This overvoltage protection is deactivated
below 30V. Powercircuit is protected up to 80V/DC. Outputs are Short Circuit
Protected.
In all these above mentioned values; a tolerance of +/-10% is applied.
Power consumption: <2W.
Transient protection: Camera may be powered directly from 12V or 24V battery
without additional electrical protection since camera has an integrated circuit
that protects the camera against over- and undervoltage, spikes, ripples and
loaddumps.
Connector/Cable: 6 wire: 2x twisted pair for data and 2 wires for power supply.
Connector 4-pin M12 d-coded for data and open wires for
power supply.
Min. cable bend radius: 50mm.
Mechanical
Housing: Anodised aluminium, black, UV resistant, light fastness >8, corrosion
proof according IEC 60068-2-52 salt mist, cyclic.
Filling: Camera is potted with automotive potting resin
Ingress protection: IP67 according to IEC 60529; dust tight and protected
against the effects of continuous immersion in water up to 1m under water for
30 minutes, IP69k according to DIN 40050-9: camera can withstand a high
pressure cleaning/washing with water: 14-16L/min. 80°C and 100 bars flow.
9
Installation manual
Electrical
Power input: Camera HMOS may only be powered by Orlaco monitor HLED. The
camera HMOS has no internal power protection.
Power consumption: <2W
Connector/Cable: 0,5m cable with Coax and molded male connector (camera
power input and video output).
Min. cable bend radius: 50mm.
Mechanical
Housing: Anodised aluminium, black, UV resistant, light fastness >8, corrosion
proof according IEC 60068-2-52 salt mist, cyclic.
Filling: Camera is potted with automotive potting resin
Ingress protection: IP67 according to IEC 60529; dust tight and protected
against the effects of continuous immersion in water up to 1m under water for
30 minutes. IP69k according to DIN 40050-9: camera can withstand a high pres-
sure cleaning with water: 14-16L/min. 80°C and 100 bars flow.
Mounting hardware: Standard stainless steel.
Shock constancy: Shock and vibration resistant for usage on trucks, cranes,
fork-lifts, maritime applications, machinery.
Camera bracket: glass reinforced polyamide, test: 50 Nm at -40°C to +85°C.
Weight: 0,24kg. including cable, bracket and mounting material. 0,30kg. in
standard packing.
Truck use: Withstand all fluids and materials used in and around trucks like:
ammonia solution 5%, ethanol 80-100%, isopropanol 5-10%, soapy water (min.
50% soap per volume), alkaline degreasing compounds(used in high pressure
washing equipment).
