Page 22 / 36
Hartley and Sugden
21. Fix the control panel on the front cover.
- 2 Parker screws 4.2X10
21
22. Placing o f the sensor s of the control pane l in the plunger
placed in the higher part of t he rear el ement.
22
23. Placing of the rectangular panel for the sensors in the
plunger.
Rectangular panel for plunger 3/4"
24. Plac ing of the clips for p lunger.
1 copper clip s for plunger 3/ 4"
24
25. Placing o f the intermediate covers and rear cover
according to model.
