2. Purpose 2
3. General 2
5. Block diagram of the electronic
parts OptiFlex-K1
6. Bill of material for service parts
OptiFlex
-K1
7. Figure for bill of material
8. Special function Service menu for
OptiFlex
-K1
9. How to perform repairs
10. Checklist of safety and function test
OptiFlex
-K1
6
7
8
10
12
13
simple repairs on the OptiFlex
-K1
. Only authorized staff may
perform repairs and maintenance as the manufacturer’s
and liability would otherwise be invalidated.
Only original parts may be used for servicing in accordance
the attached spare parts list.
1
2
3
4
unit is switched on. Always switch the OptiFlex
-K1
off before connecting or disconnecting a plug.
The locks for spiral cable for the hand-held program-
ming unit have to be closed at all times.
When you assembling with electronic parts make sure
to use ESD (Electro Static Discharge) equipment.
If you have to exchange any of the printed circuit boards
including the knee electronics or motor control you have
to perform a calibration.
Possible errors: Errors will be displayed on the hand-
held programming unit as follows shown:
Wrong angle information
-> Replace knee electronics (Pos. 3)
-> Replace motor control (Pos. 20)
Connection to the potentiometer is interrupted
-> Replace knee electronics (Pos. 3)
-> Replace motor control (Pos. 20)
The motor driver IC reported an error
The motor did not turn properly
-> Replace the motor (Pos. 21)
1 01.08.2007 S. Herr Service Manual
created
XX
