HOW TO ATTACH THE SEAT TO THE FRAME
AFTER APPLYING BRAKES, P
LACE
THE SEAT ON THE MOUNTING
PLATE (Fig. A)
PUSH THE SEAT BACKWARDS SLIDING IT
ON TO THE MOUNTING PLATE
OPERATE THE LOCKING LEVER. (AS IN
FIG. B) THE CLICK OF THE SAFETY RED PUSH-
BUTTON MEANS THAT IS WELL LOCKED
FIG. A
VIEW FROM ABOVE THE FRAME
MOUNTING
PLATE
VIEW
FROM BEHIND
LOCKING
LEVER
DER YTEFAS
PUSH-BUTTON
FIG. B
LOCKS
UNLOCKS
MAKE SURE THE SEAT IS
IN THE MOUNTING PLATE
BEFORE LOCKING IT WITH
THE LEVER
