ERGONOMIC HEADREST
942
Adjustable in height, tilt, back and forwards
WRENCH
W
RENCH
NUTS
2 SCREWS
TO FIX THE
HEADREST
MOUNTING
1. REMOVE THE PARTS POINTED ON FIGURE A
2. TIGHTEN THE TWO SCREWS OF THE LEFT SIDE
3. REMOVE THE LOWER KNOB AND MOVE ITS SCREW WITHOUT REMOVING IT
4. TIGHTEN THE TWO SCREWS OF THE RIGHT SIDE
5. TIGHTEN THE KNOB
6. FIX THE CUSHION ON THE BACKREST (FIG.F)
