HOW TO USE Bug WITH BASE 856
HOW TO ATTACH THE SEAT TO THE FRAME
AFTER APPLYING BRAKES, PLACE THE SEAT ON THE
MOUNTING PLATE (FIG. A)
PUSH THE SEAT BACKWARDS SLIDING IT ON TO THE
MOUNTING PLATE
ENGAGE THE LOCKING LEVER (AS IN FIG. B) THE
CLICK MEANS THE SAFETY DEVICE IS LOCKED
MAKE SURE THE SEAT IS IN THE
MOUNTING PLATE BEFORE
LOCKING IT WITH THE LEVER
LOCKING LEVER
SAFETY RED
PUSH-BUTTON
LOCKS
UNLOCKS
MOUNTING PLATE
FIG. A
FIG. B
