EN 
+
After the self-test, the smart antenna
function is shown on the display for
 seconds.
If positioned horizontally, the +
transmits on the X-antenna.
If positioned vertically, the +
transmits on the Y-antenna.
SMART ANTENNA
TRANSMISSION
Once the self-test has successfully concluded,
the + will transmit and the transmission
lights flash on the screen.
The battery icon shows the remaining
battery capacity.
X
Y
Z
INSTRUCTIONS
