ZOOM+

TRANSMISSION
Once the self-test has successfully concluded,
the ZOOM+ will transmit and the transmission
lights flash ( ) on the screen.
After the self-test, the smart antenna
function is shown on the display for
 seconds.
If positioned horizontally, the
ZOOM+ transmits on the X-antenna.
If positioned vertically, the
ZOOM+ transmits on the Y-antenna.
SMART ANTENNA
X
Y
Z
