Oru Kayak BAY+ - Step 3: Bulkhead Unhooking and Seam Channel Attachment; Unhook Bulkhead Snaphook from D-ring; Attach Loose Seam Channels

seam
channel
seam
channel
B
BOW
STERN
A
Fit one loose seam
channel tightly end-to-end
with the permanently-
attached seam channel at
the bow. There should be
no gap between the two
seam channels. (See close
up.) Repeat at the stern.
B
B
loose
seam
channel
no
space
permanently
attached seam
channel
6 ORU KAYAK | ASSEMBLY GUIDE
Step 3: Unhook bulkhead & attach seam channels
Unhook snaphook
from D-ring.
(Later, when folding the
kayak back into its box,
you will re-hook.)
The bulkhead hook keeps the front bulkhead and footrest out of the way while folding the kayak into box form. Four seam channels
seal the deck (top) of the kayak. Two are permanently attached to one side of the deck, and you’ll attach the other two.
A
unhook
