Oru Kayak HAVEN - Getting Familiar with Floorboard Components; Keyhole Plates; Alignment Plates; Seat Column Plates

3 ORU KAYAK | HAVEN KAYAK ASSEMBLY GUIDE
© 2019 ORU KAYAK, INC. ALL RIGHTS RESERVED 0116
Keyhole plates: Hold
the reinforcing rod in
securely.
Getting Familiar floorboard components
Stern floorboard: Reinforces
kayak bottom and holds the
rear and middle seat.
Alignment plates:
Attached to the
floorboards. Ensure
proper installation of
floorboards in boat.
1
1
2
3
3
Seat column plates:
Connect to the seat
column holding the
seat system in place.
4
Bowties: Allow you
to easily set up
multiple seating
configurations.
6
STERN
BLUE
REDG REEN
RED BLUE
RED
Bow floorboard: Reinforces
kayak bottom and holds the
front seat.
5
2
4
