Page 34
Installation and Operation Manual - 2000
ENGLISH
7.2.4 Clearances in an alcove
MOBILE HOME CLEARANCES
(INSTALLATION WITH DOUBLE WALL PIPE
CONNECTOR)
DISTANCES
3
FROM PIPE CONNECTOR WITH
DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
A 9" (229 mm) 9" (229 mm) D 12 ¼" (311 mm) 12 ¼" (311 mm)
B 19" (483 mm) 19" (483 mm) E 28 ¼ (718 mm) 28 ¼ (718 mm)
K 48" (122 cm) 48" (122 cm)
L 77" (196 cm) 77" (196 cm)
7.2.5 Clearances For Mobile Homes
It is strictly forbidden to install a unit with single wall pipe in a mobile home.
MOBILE HOME CLEARANCES
(INSTALLATION WITH DOUBLE WALL PIPE
CONNECTOR)
DISTANCES
3
FROM PIPE CONNECTOR WITH
DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
A 11" (279 mm) 11" (279 mm) D 14 ¼" (362 mm) 14 ¼" (362 mm)
B 18" (457 mm) 18" (457 mm) E 27 ¼" (692 mm) 27 ¼" (692 mm)
C 11" (279 mm) 11" (279 mm) F 20 ½" (521 mm) 20 ½" (521 mm)
K 48" (122 cm) 48" (122 cm)
L 84" (213 cm) 84" (213 cm)
7.2.6 Clearances with heat shield AC02710 in a mobile home
MOBILE HOME CLEARANCES
(INSTALLATION WITH DOUBLE WALL PIPE
CONNECTOR)
DISTANCES
3
FROM PIPE CONNECTOR WITH
DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
A 3" (76 mm) 3" (76 mm) D 6 ¼" (159 mm) 6 ¼" (159 mm)
B 6" (152 mm) 6" (152 mm) E 15 ¼" (387 mm) 15 ¼" (387 mm)
C 3" (76 mm) 3" (76 mm) F 12 ½" (318 mm) 12 ½" (318 mm)
K 48" (122 cm) 48" (122 cm)
L 84" (213 cm) 84" (213 cm)
3
The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances above
mentioned.
