Page 33
Installation and Operation Manual - 2000
ENGLISH
7.2.2 Clearances With Ceiling (L) Lowered to 77" (196 cm)
APPLIANCE CLEARANCES (INSTALLATION
WITH SINGLE WALL PIPE CONNECTOR)
APPLIANCE CLEARANCES (INSTALLATION
WITH DOUBLE WALL PIPE CONNECTOR)
Canada USA Canada USA
A 14 ½" (368 mm) 11" (279 mm) A 9" (229 mm) 9" (229 mm)
B 19" (483 mm) 18" (457 mm) B 19" (483 mm) 19" (483 mm)
C 10" (254 mm) 10" (254 mm) C 7" (178 mm) 7" (178 mm)
K 48" (122 cm) 48" (122 cm) K 48" (122 cm) 48" (122 cm)
L 77" (196 cm) 77" (196 cm) L 77" (196 cm) 77" (196 cm)
If the above clearances are met, then the distances measured from the flue outlet will be:
DISTANCES FROM PIPE CONNECTOR WITH
SINGLE WALL PIPE CONNECTOR
DISTANCES
2
FROM PIPE CONNECTOR WITH
DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
D 18" (457 mm) 14 ½" (368 mm) D 12 ¼" (311 mm) 12 ¼" (311 mm)
E 28 ½" (724 mm) 27 ½" (699 mm) E 28 ¼" (718 mm) 28 ¼" (718 mm)
F 19 ¾" (502 mm) 19 ¾" (502 mm) F 16 ½" (419 mm) 16 ½" (419 mm)
7.2.3 Clearances with heat shield (AC02710) and ceiling lowered to 77" (196 cm)
Note that to reduce the clearances of an appliance using a single wall pipe connector, the use
of a heat shield certified with the single wall pipe connector to be used as close as 6" from
combustible materials must be used. Only in this case, the same clearances as a certified
double wall pipe connector can be used.
APPLIANCE CLEARANCES (INSTALLATION
WITH DOUBLE WALL PIPE CONNECTOR)
DISTANCES
2
FROM DOUBLE WALL PIPE
CONNECTOR
Canada USA Canada USA
A 5" (127 mm) 5" (127 mm) D 8 ¼" (210 mm) 8 ¼" (210 mm)
B 6" (152 mm) 6" (152 mm) E 15 ¼" (387 mm) 15 ¼" (387 mm)
C 5" (127 mm) 5" (127 mm) F 14 ½" (368 mm) 14 ½" (368 mm)
K 48" (122 cm) 48" (122 cm)
L 80" (203 cm) 80" (203 cm)
2
The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances above
mentioned.
