Osburn 2200 - Appendix 3: Optional Air Circulation Fan

2200InstallationandOperationManual 
______________________________________________________________________________45
APPENDIX 3: INSTALLATION AND USE OF OPTIONAL AIR
CIRCULATIONFAN

Anoptionalfancan beinstalledonthe backof
the stove to increase the flow of air past heat
exchange surfaces and to help circulate warm
air in the room. When used regularly, the fan
canprovideasmallincreaseinefficiency,upto
2percent.However,theuseofafanshouldnot
be used as a way to gain more output from a
stove that is undersized for the space  it is
intendedtoheat.Youcanpurchasethisoption
through your Osburn dealer. Make sure to
specifythispartnumber:#OA10510


Your fan has a rheostat, see the illustration on
the right to identify the different adjustment
positions; either from high (HI) to low (LO) or
closed(OFF).


Whenusingtheoptionalfan,allowthestovetoreachoperatingtemperature(approximatelyone
hour),before turning iton.The increased airflow from thefancoolsthefirebox andcouldaffect
thestart‐upcombustionefficiencyifthefanisturnedontooearly.
CAUTION: ENSURE THAT THE FAN’S POWER
CORDISNOTINCONTACTWITHANYSURFACE
OFTHESTOVETOPREVENTELECTRICALSHOCK
OR FIRE DAMAGE. DO NOT RUN THE POWER
CORDBENEATHTHESTOVE.

