Page 40
Installation and Operation Manual - Osburn 3500
APPENDIX 2: BLOWER AND OPTIONAL THERMODISC INSTALLATION
A blower (D) is included with this wood stove. A thermodisc, sold separately, can also be installed
(A). It allows the blower to operate only when the stove is hot enough. See the instructions provided
with the thermodisc for more details.
Screw the blower (D) in place using the screws (C) included in the installation manual. Screw the
thermodisc (A) with the screws (B) supplied with the thermodisc on the back of the stove.
Ensure that the blower’s power cord is not in contact with any surface of the stove to
prevent electrical shock or fire damage. Do not run the power cord beneath the stove.
C
D
B
A
