IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 OA10163 BLACK DOOR OVERLAY 1
1 OA10164 BRUSHED NICKEL DOOR OVERLAY 1
2 SE46101 OSBURN 3500 INSTRUCTIONS MANUAL KIT 1
3 AC01281 RIGID FIRESCREEN 1
4 30898 ROUND WOODEN BLACK HANDLE 3
5 SE24297 OSBURN 3500 DOOR ASSEMBLY 1
6 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
7 SE65024 REPLACEMENT HANDLE WITH LATCH KIT 1
8 AC09185 DOOR LATCH KIT 1
9 30187 STAINLESS WASHER ID 17/64" X OD 1/2" 2
10 30025 1/4-20 X 1/2" PAN-HEAD QUADREX BLACK SCREW 1
11 SE70902 OSBURN DOOR GLASS 19 5/8''W X 11 5/8''H X 12 11/16''H 1
12 AC06400 3/4" X 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET 1
13 PL70814 RIGHT GLASS FRAME 1
14 AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 1
15 PL70815 RIGHT GLASS FRAME 1
16 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
17 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 5
18 SE70852 ASH LIP ASSEMBLY 1
19 SE70787 AIR CONTROL DAMPER ASSEMBLY 1
20 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
21 30506 SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK 2
22 AC01336 5"Ø FRESH AIR INTAKE KIT FOR WOOD STOVE ON PEDESTAL 1
23 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A 10
24 PL70823 PEDESTAL BACK PANEL 1
25 PL70824 PEDESTAL 1
26 PL70837 AIR CONTROL COVER 1
27 SE70820 ASH DRAWER ASSEMBLY 1
28 28062 BLACK DRAWER HANDLE 3 25/32" 1
29 30108 MECHANICAL SCREW M4 X 4MM PAN PHILLIPS ZINC 2
30 PL70996 DÉCORATIVE PANEL 2
31 24096 ROUND CAST IRON ASH PLUG 1
32 PL70995 AIR DEFLECTOR 1
33 29020 4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD 17
34 PL36056 2" X 9" 1 1/4" REFRACTORY BRICK HD 8
