RMX Series Technical Service Manual 17
4860-5030-5 TR MJE15033 1 Q206
4860-5050-5 TR 2SC5200 T0-3P (L) 3 Q208, Q210, Q212
4860-5060-5 TR 2SA1943 T0-3P (L) 3 Q203, Q207, Q209
8910-0062-0 CE 80V 4700U 20% RL 25X 2 C220, C221
8910-0274-0 THERMAL PTC 60C 100 ohm 1 R4
8910-0488-0 ROD THERMISTOR NTC 50ohm 1 R234
Channel 2 SMT parts
150F-104K-6-CF CER2 1206 X7R 50V 100N 3 C100, C102, C104
150F-181K-J-BD CC 50V 180P 10% 0805 4 C101, C103, C201, C203
150F-222K-6-CF CC 50V 2200pF 10% 1206 1 1 C215
150F-560K-J-BD CC 50V 56pF 10% 0805 1.2 2 C110, C210
150H-102J-6-CF CC 100V 0.001µF 5% 1206 1 C214
15CG-560J-6-CF CTC 0/30 56P 5% 1206 2 C111, C211
3131-9730-0 IC NE5517D 1 U10
4720-101J-J RMG 1/10W 100R 5% 0805 6 R109, R110, R127, R209, R211, R227
4720-102J-J RMG 1/10W 1K 5% 0805 3 R102, R126, R202
4720-103A-J RMG 1/10W 10K 1% 0805 8 R100, R101, R105, R106, R200, R201, R205, R206
4720-103J-J RMG 1/10W 10K 5% 0805 3 R103, R203, R228
4720-152J-J RMG 1/10W 1.5K 5% 0805 1 R229
4720-203A-J RMG 1/10W 20K 1% 0805 4 R117, R121, R217, R221
4720-271J-J RMG 1/10W 270R 5% 0805 6 R111, R113, R120, R210, R213, R220
4720-332J-J RMG 1/10W 3.3K 5% 0805 1 R24
4720-393J-J RMG 1/10W 39K 5% 0805 2 R107, R207
4720-470J-J RMG 1/10W 47R 5% 0805 1 R224
4720-472J-J RMG 1/10W 4.7K 5% 0805 2 R114, R214
4720-752J-J RMG 1/10W 7.5K 5% 0805 2 R108, R208
4721-154A-6 RMG 1/8W 150K 1% 1206 4 R118, R119, R218, R219
4721-154J-6 RMG 1/8W 150K 5% 1206 2 R104, R204
4721-333J-6 RMG 1/8W 33K 5% 1206 2 R22, R23
4721-394J-6 RMG 1/8W 390K 5% 1206 2 R116, R216
4721-473J-6 RMG 1/8W 47K 5% 1206 1 R225
4721-821J-6 RMG 1/8W 820R 5% 1206 4 R115, R215, R230, R232
4804-1480-3 DIODE LL4148 SM 15 D102, D103, D105, D106, D202–D206, D211–D216
4853-9060-3 TR 3906 PNP SM 2 Q100, Q200
4860-0640-3 TR 3904 HFE 100-300 SM 2 Q201, Q202
Input board
150F-471J-5-OF CC 50V 470pF 5% RL 8x3.5 4 C1–C4
7010-9860-0 26 PIN IEC RIBBON CABLE 1 J1
2113-1337-1 XLR FEMALE CONN. 2 J101, J201
2113-1652-0 PHONE JACK 06.4 2 J102, J202
2113-1335-0 5 POLE SPEAKER TERMINAL 1 J5
5200-4713-0 10 POLE DIP SWITCH 1 SW1
Output board
2113-1336-1 SPEAKON NEUTRIK 4 WIRE 2 J100, J200
2113-1338-0 4-POLE SPEAKER TERMINAL 1 J103
4154-2111-0 OUTPUT POST PLUG FOR CE 2 For European models only
4154-2121-0 OUTPUT POST PLUG FOR CE 2 For European models only
Channel 2 module (continued)
QSC part # Description Qty. Notes or Component Reference
