OSC RMX 850 - RMX Assembly;Disassembly Diagram Part 2

26 QSC Audio Products, Inc.
CHASSIS
SCREW
4 REQD
WIRE ASSY
NUT
SCREW
5 REQD
SCREW
6 REQD
KNOB
2 REQD
D
SCALE
1/2
SHEET
2 OF 2
DWG NO.
PA-002450-00
REV
DWG NO.
PA-002450-00
2
SH
REV
87654321
87654321
A
B
C
D
A
B
C
D
THIS DOCUMENT CONTAINS PROPRIETARY
INFORMATION WHICH IS THE PROPERTY
OF QSC AUDIO PRODUCTS, THAT MAY NOT
BE DISCLOSED, REPRODUCED OR USED
WITHOUT EXPRESS WRITTEN CONSENT FROM
QSC AUDIO PRODUCTS.
7.2 RMX Assembly/Disassembly Diagram 2 of 2
(All models)
