RMX Series Technical Service Manual 23
4720-472J-J RMG 1/10W 4.7K 5% 0805 8 R114, R138, R174, R179, R187, R193, R214, R238
4720-473J-J RMG 1/10W 47K 5% 0805 1 R183
4720-474J-J RMG 1/10W 470K 5% 0805 2 R172, R185
4720-592A-J RMG 1/10W 5.9K 1% 0805 2 R171, R184
4720-750J-J RMG 1/10W 75R 5% 0805 1 R124
4720-752J-J RMG 1/10W 7.5K 5% 0805 2 R108, R208
4720-821J-J RMG 1/10W 820R 5% 0805 2 R111, R211
4721-101J-6 RMG 1/8W 100R 5% 1206 1 R197
4721-154J-6 RMG 1/8W 150K 5% 1206 6 R104, R173, R178, R186, R192, R204
4721-4643-6 RMG 1/8W 464K 1% 1206 3 R166, R167, R266
4721-473J-6 RMG 1/8W 47K 5% 1206 1 R125
4721-683A-6 RMG 1/8W 68K 1% 1206 4 R22A, R22B, R23A, R23B
4721-821J-6 RMG 1/8W 820R 5% 1206 4 R115, R130, R132, R215
4721-824J-6 RMG 1/8W 820K 5% 1206 2 R116, R216
4804-1480-3 DIODE LL4148 SM 18 D102–D106, D111–D116, D171, D173, D177, D202, D203, D205, D206
4853-9060-3 TR 3906 PNP SM 4 Q100, Q172, Q175, Q200
4860-0640-3 TR 3904 HFE 100-300 SM 4 Q101, Q102, Q171, Q173
Channel 2 module
153F-223J-5-LQ CM 50V 0.022UF 5% RL 2 C216, C219
153F-332J-5-KW CM 50V 3300pF 5% RL 6x12 2 C272, C279
153R-104J-5-YRM CM 250V 0.1u 5% RL 2 C274, C275
153R-152J-5-XQ CM 250V 0.0015UF 5% RL 1 C214
153R-683J-5-WWM CM 250V 0.068u 5% RL 2 C224, C226
157E-107M-5-KW CE 25V 100uF 20% RL 6x12 2 C273, C280
157E-226M-5-IUN CE 25V 22uF 20% RL 5X11 1 C229
157F-476M-5-LU CE 50V 47uF 20% RL 1 C8
157Q-106M-5-IU CE 35V 10uF 20% RL 5x11 1 C271
157R-475M-5-OV CE 250V 4.7u 20% RL 1 C7
1804-1040-0 SPRNG COIL 2uH(14gaWIRE) 1 L200
2102-031S-004 3 PIN ST. WAFER 1 J257
2102-130S-003 13 PIN WAFER P2.0 ST. 1 J204
3700-4531-G LED 04mm GREEN W/STAND 1 LD1
4134-8851-0 FUSE HOLDER (DIA.6.3MM 2 REF: F200
4715-100J-2 RMF 1/4W 10R 5% AT 1 R263
4715-101J-2 RMF 1/4W 100R 5% AT 1 R264
4718-123J-2-X RMF 1W 12K 5% AT METAL 2 R277, R294
4718-153J-2-X RMF 1W 15K 5% AT METAL 1 R265
4718-220J-2-P RMF 1W 22R 5% AT FP 2 R236, R237
4718-3R3J-1-X RMF 1W 3.3R 5% AL 2 R246, R247
4719-1R5J-1-X RMF 2W 1R5 5% AL METAL 2 R281, R282
4719-333J-2-X RMF 2W 33K 5% AT METAL 2 R2, R5
4719-5R6J-1-X RMF 2W 5.6R 5% AL METAL 1 R260
471A-022K-5-N RMF 3W 0.22R 10% RL RGC3 8 R242, R243, R248, R249, R252, R253, R256, R259
471B-120J-1-X RMF 5W 12R 5% AL METAL 4 R254, R255, R261, R262
471B-222J-1-X RMF 5W 2.2K 5% AL METAL 3 R257, R258, R298
471B-512J-1-X RMF 5W 5.1K 5% AL METAL 2 R280, R288
471B-822J-1-X RMF 5W 8.2K 5% AL METAL 4 R218, R219, R233, R235
4756-1016-3-06 SVR H6 100R RH0615C 1 R231
4756-2226-3-06 SVR 2.2K H3 7X7.6 R0615C 2 R239, R240
4804-0040-1 DIODE IN4004 AL 5 D1, D11, D13, D217, D218
4804-9340-2 DIODE IN4934 AT 2 D208, D209
4837-3B20-2 DZ 1/2W 3.8-4.0V AT 1 D270
4837-5B10-2 DZ 1/2W 5.5-5.8V AT 2 D207, D210
4838-10V6-2 DZ 1.3W 10V AT TEMIC 1 D274
4838-12V6-2 DZ 1W 12V AT TEMIC 1 D278
4838-15V6-2 DZ 1W 15V AT TEMIC 2 D8, D15
4840-2190-0 DIODE MUR1520 15A 200V 2 D275, D276
Channel 1 module (continued)
QSC part # Description Qty. Notes or Component Reference
