RETSPL table
Hz TDH-39
IEC 60318-3/NBS 9A
from ANSI/ASA S3.6-2010, Table 5
Insert phones/
IPSI probe
from ANSI/ASA S3.6-2010, Table 7
500 11.5 5.5
1 k 7 0
2 k 9 3
3 k 10 3.5
4 k 9.5 5.5
Power supply
Friwo FOX18 FW8001M 100-240 VAC/12 VDC, 50-60 Hz
USB port connector
For PC connection
Warm-up time
< 10 minutes
Physical attributes
Dimensions (WxDxH): 225 x 180 x 55 mm (8.9 x 7.0 x 2.2 in)
Weight: 1.3 kg (2.9 lb)
Operating environment
Ambient temperature: +15 to +35°C (+59 to 95°F)
Relative humidity: 30% to 90% (non-condensing)
Air pressure: 700 hPa to 1060 hPa
Transport and storage
Ambient temperature: -20°C (-4°F) or +60°C (140°F)
Relative humidity: 90% or less (non-condensing)
Air pressure: 700 hPa to 1060 hPa
Disposal
T830/T840 can be disposed of as normal electronic waste, according to WEEE and local regulations.
Inmedico A/S - T830/T840
User Guide
