PRESSURE/FLOW
TECHNICAL DATA
SOUND DATA
INPUT/FLOW
RFE 315 E
RFE 315 E, 580 l/s 545 Pa L
pA
L
wA
tot dB (A) 63 125 250 500 1K 2K 4K 8K
Environment 73 80 52 61 66 71 77 74 70 63
Inlet 82 68 72 74 70 78 76 75 69
Outlet 87 70 71 76 79 83 80 78 72
DIMENSIONS (mm)
ACCESSORIES
Duct clamp, mounting bracket, safety grille, thermostat,
louvre & back draught shutter, transformer controllers
General fan facts, page 30-31.
246
251
462
194
219
244
194
489
210
355
594
Ø13,1
210
489
355
594
45
19445
355
355
Voltage, V/Hz 230/50
Current, A 8,50
Input, kW 1,83
Speed, rpm 1400
Wiring diagram 4040001
Capacitor, µF 30
Max.temp.
o
C50
Rotation direction Right
Pole number, motor 4
RFT 315 C
Single inlet radial fan with forward curved impeller. 3-phase
RFE 315 E
Single inlet radial fan with forward curved impeller. Single phase
PRESSURE/FLOW
TECHNICAL DATA
SOUND DATA
246
251
462
194
219
244
194
489
210
355
594
Ø13,1
INPUT/FLOW
RFT 315 C
RFT 315 C, 460 l/s 270 Pa L
pA
L
wA
tot dB (A) 63 125 250 500 1K 2K 4K 8K
Environment 63 70 43 50 58 63 67 64 61 50
Inlet 73 58 63 63 63 69 67 66 56
Outlet 78 64 63 67 72 72 71 70 62
DIMENSIONS (mm)
ACCESSORIES
Duct clamp, mounting bracket, safety grille, thermostat,
louvre & back draught shutter, transformer controllers
General fan facts, page 30-31.
210
489
355
594
45
19445
355
355
Voltage, V/Hz 3x400Y/3x230/50
Current, A 1,90/3,29
Input, kW 0,79
Speed, rpm 890
Wiring diagram 4040004/4040003
Capacitor, µF -
Max.temp.
o
C65
Rotation direction Right
Pole number, motor 6
