RFE 160 A
Single inlet radial fan with forward curved impeller. Single phase.
RFE 160 C
Single inlet radial fan with forward curved impeller. Single phase
PRESSURE/FLOW
TECHNICAL DATA
SOUND DATA
INPUT/FLOW
RFE 160 A
DIMENSIONS (mm)
ACCESSORIES
Duct clamp, mounting bracket, safety grille, thermostat,
louvre & back draught shutter, transformer controllers
General fan facts, page 30-31.
RFE 160 A, 70 l/s 110 Pa L
pA
L
wA
tot dB (A) 63 125 250 500 1K 2K 4K 8K
Environment 50 57 29 35 48 54 52 49 45 40
Inlet 62 40 53 57 57 55 51 50 42
Outlet 64 44 55 56 59 61 51 51 47
92
105
120
90
109
124
90
258
100
144
233
Ø7,1
123
275
180
316
40
8540
160
160
8
PRESSURE/FLOW
TECHNICAL DATA
SOUND DATA
INPUT/FLOW
RFE 160 C
RFE 160 C, 105 l/s 490 Pa L
pA
L
wA
tot dB (A) 63 125 250 500 1K 2K 4K 8K
Environment 63 70 41 49 61 63 63 66 63 58
Inlet 74 59 65 70 67 66 66 64 62
Outlet 78 61 66 69 71 72 71 70 68
DIMENSIONS (mm)
ACCESSORIES
Duct clamp, mounting bracket, safety grille, thermostat,
louvre & back draught shutter, transformer controllers
General fan facts, page 30-31.
92
105
120
90
109
124
90
258
100
144
233
Ø7,1
94
216
149
255
40
9440
160
160
Voltage, V/Hz 230/50
Current, A 0,28
Input, W 64
Speed, rpm 1270
Wiring diagram 4040001
Capacitor, µF 2
Max.temp.
o
C65
Rotation direction Right
Pole number, motor 4
Voltage, V/Hz 230/50
Current, A 1,30
Input, W 300
Speed, rpm 2150
Wiring diagram 4040001
Capacitor, µF 6
Max.temp.
o
C50
Rotation direction Right
Pole number, motor 2
Connected = Connected on outlet.
Not connected = Not connected on outlet.
Connected = Connected on outlet.
Not connected = Not connected on outlet.
