OTC Tools 1543 - Parts List; Replacement Part Kits

Parts List & Operating Instructions Form No. 526444, Sheet 2 of 2, Back
1 1 Carriage Frame Assembly
2 1 Locknut
3 1 Washer
4 5 Washer
5 1 Drive Screw
6 1 Trunnion Assembly
7 2 Locknut
8 2 Bolt
9 1 Axle Assembly
10 2 Trunnion Screw
11 2 Wheel
12 2 Washer
13 2 Cotter Pin
Item
No. Qty. Description
Item
No. Qty. Description
14 1 Cotterless Pin
15 6 Bolt
16 1 Cotterless Hitch Pin
17 1 Handle
18 1 Handle Grip
19 1 Crank Handle
20 1 Crank
21 2 Expansion Pin
22 1 Carriage and Plate Assembly
23 2 Stop Bar
24 1 Hook
25 6 Locknut
26 6 Washer
Parts List
Replacement Part Kits
Item
No. Qty. Description
Drive Screw Kit
No. 526459 includes:
2 1 Locknut
3 1 Washer
4 1 Washer
5 1 Drive Screw
6 1 Trunnion Assembly
19 1 Crank Handle
20 1 Crank
21 2 Expansion Pin
Handle Kit
No. 526458 includes:
16 1 Cotterless Hitch Pin
17 1 Handle
18 1 Handle Grip
Wheel Kit
No. 526457 includes:
11 1 Wheel
12 1 Washer
13 1 Cotter Pin
Hardware Kit
No. 526460 includes:
2 1 Locknut
3 1 Washer
4 5 Washer
7 2 Locknut
8 2 Bolt
10 2 Trunnion Screw
12 2 Washer
13 2 Cotter Pin
14 1 Cotterless Pin
15 2 Bolt
16 1 Cotterless Hitch Pin
21 2 Expansion Pin
23 2 Stop Bar
24 1 Hook
25 6 Locknut
26 6 Washer
Item
No. Qty. Description
