Appendices
Appendix A – Specifications
Lathe
Swing over bed 8.27” (210 mm)
Distance between centers 16.14” (410 mm)
Spindle bore 0.79” (20 mm)
Spindle taper MT #3
Tailstock taper MT #2
Spindle speed 0-2000 RPM
Compound travel 3.50” (89 mm)
Cross slide travel 4.50” (114 mm)
Motor output power 1000 W
Thread range 8-56 TPI (13 thread pitches)
0.25-3.0 mm (17 thread pitches)
Milling Head Accessory
Drilling capacity .39” (10 mm)
End milling capacity .39” (10 mm)
Face milling capacity .79” (20 mm)
Spindle taper MT #2
Spindle speed
Low range: 100-1000 RPM ± 10%
High range: 100-2000 RPM ± 10%
Spindle travel 1.18” (30 mm)
Headstock travel 5.51” (140 mm)
Spindle angle
30°L, 45°R
Motor 150 W
