2
Choose the most convenient port
on your tank, but not the one
that is normally used for filling.
This installation is intended to be
permanent or not often removed.
See following page for more
information.
Clean around the tank’s port to
avoid contamination of fuel;
Remove any rust or dirt on the plug
or fitting threads.
Communicator
Connector
SS304
Polypropylene
Reducer 2” NPT
PUR Jacketed Cable
Nylon 6/6 with TPE
Sealing Cord Grip
Device Anatomy
Ideal position
Start clean
Polypropylene
Elbow 1” NPT
Black Nylon
Cover Tip
Sensor/Transducer
SS304
To Next Page
