Maximizing Monitor Performance
1 2
3
Not Optimal.
Installing a monitor in position 1, 2 or 3 can cause
impediments to signal transmission which can result
in inaccurate readings and premature drainage of a
monitor’s battery.
4 5
6
Optimal Position.
Installing a monitor is position 4, 5 or 6 will ensure
maximum signal strength which will conserve battery
life and provide accurate readings.
Too close to wall. Can cause signal
interference.
Monitor installed too horizontally.
Can cause signal interference.
Mounted vertically, top of tank, far
from walls. Maximizes signal strength.
Mounted vertically, side of tank,
far from walls. Maximizes signal
strength. Suggested wall mount
bracket: ACWMB1.
