44
5.7. Wheel lock for one-handed operation (Fig. 12)
INFORMATION!
Please note that the wheel lock lever extension must always be attached when re-
leasing or engaging the wheel lock.
Recommended especially for hemiplegics. It can be activated either on the right or left side and
ensures the safe locking of both rear wheels with a pull-wire system.
5.8. Tray (Fig. 13)
Serves as a supporting surface during meals, when working or when playing. The clear material
allows visibility of the legs and correction of the sitting posture.
12 13
5.9. Lap belt (Fig. 14)
Prevents the wheelchair user from falling out of the wheelchair.
5.10 Elevating footrest (Fig. 15)
Allows positioning of the leg at different angles. Upon manipulation of the release lever which is
integrated into the legrest bearing the footrest angle can be adjusted in small increments.
14 15
