9 Technical Data
Overall length (in cm)
Rear wheel size
20x1 3/8” 22x1 3/8” 24x1 3/8”
Module
Rear axle po-
sition
Front axle po-
sition
Rear axle po-
sition
Front axle po-
sition
Rear axle po-
sition
Front axle po-
sition
M1 - - 100 90 103.5 94
M2, M3
- - 100.5 90 104 94
M4 - - 100.5 87.5 104 91
M5 - - 97.5 81.5 101 85
M6 89.5 79 92 81.5 95.5 85
Overall width (in cm)
1)
Seat
width
Standard rear wheel
max.
Rear wheel with drum
brake max.
28 47 49.5
30.5 49.5 52
33 52 54.5
35.5 54.5 57
38 57 59.5
40.5 59.5 62
43 62 64.5
45.5 64.5 67
48 67 69.5
50.5 69.5 72
53 72 74.5
55.5 74.5 77
58 77 79.5
1)
Applicable to push ring attachment, narrow (for push ring attachment, wide: +2 cm) and a 0° camber of the
rear wheels.
