12 VOLT INVERTER/CHARGER

6V Battery Wiring Examples

DC DISCONNECT (FUSE OR CIRCUIT

BREAKER)

6 VOLT

SERIES/12 VOLT FX

12 VOLT INVERTER/CHARGER

SERIES/PARALLEL/12 VOLT FX

6 VOLT

SERIES STRING 1 CONNECTS TO

INVERTER/CHARGER’S POSITIVE

TERMINAL

DC DISCONNECT (FUSE OR CIRCUIT

BREAKER)

SERIES STRING 2

SERIES STRING 1
