Please check you have all the fi ttings listed below
M5x15 Bolt x4
M6x25 Bolt x24
M6x145 Bolt x8
Ruler - Use this ruler to help correctly identify the screws
Tools required
A
D
F
E
M5 Washer x4
Body Spacer x8
B
M5 Nut x4
C
Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings
may be supplied than are required.
0 5 10 15 20 25 30 35 40 45 50
55 60
65 70 75 80
85 90 95 100
110 115 120 125 130 135 140 145 150
155 160
165 170
105
Components - Fittings
0 102030405060708090100110 120 130 140 150
0123456
Phillips screwdriver
Spanner
Ruler/tape measure
9
