Outback Spectrum - Page 15

Assembly Instructions
Attach the drip tray
right bracket
10
onto
barbecue body using
M5x15 bolts
A
, M5
washers
B
and M5 Nuts
C
.
NOTE: Ensure that the
tabs of the brackets
which to stop the drip
tray are located at the
back of the barbecue.
Step 9
Step 8
14
Attach the drip tray
left bracket
9
onto
barbecue body using
M5x15 bolts
A
, M5
washers
B
and M5 Nuts
C
.
NOTE: Ensure that the
tabs of the brackets
which to stop the drip
tray are located at the
back of the barbecue.
9
A
B
C
9
A
B
C
10
10
