PRELIMINARY STEPS
7
TM
1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your Filter Pump.
2. It is recommended to have some petroleum jelly (not included) on hand for lubricating the gaskets and o-rings.
FILTER PUMP IMPORTANT NOTES
FILTER PUMP POWER INFO
PARTS LIST
1. The installer shall follow the written instructions provided for the operation of the filter pump system.
2. All electrical components shall be installed in accordance with Article 680 of the 2017 National Electrical Code (NEC
®
) or its latest approved edition.
3. The maximum capacity of 1” diameter chlorine tablets of Outbound
TM
patented Filter Cartridge
7
(U.S. Pat. 7,005,062):
a. Type D cartridges: 2
b. Type A/C cartridges: 6
Check your chlorine levels to determine the adequate number of chlorine tablets to add. The Cartridge will automatically dispense chlorine into the pool as the
Pump runs. You must use a filter cartridge with a central core mesh divider (see p. 8) to dispense chlorine.
The Filter Cartridge
7
is for dispensing 1" chlorine tablets ONLY. DO NOT use this Cartridge to dispense powdered chlorine, shock treatment, or any other types
of chemicals as this will damage the pump, filter cartridge and pool.
Model
SFX600
SFX1000
SFX1500
Wattage
70 Watts
115 Watts
180 Watts
Amperage
1.7 Amps
1.4 Amps
3.1 Amps
Qty.
1
1
1
1
1
1
1
1
1
1
2
1
1
Parts Name
Motor Seal Nut
Rubber Nozzle
Pump Motor Assembly
Canister Gasket / Motor Seal
Top Cover
Weir Foam
Type D Filter Cartridge (SFX600 only)
Type A/C Filter Cartridge (SFX1000 or SFX1500)
Weir
Skimmer Canister
Hose Connection O-Ring
Hose Clamp
Return Hose
90° Elbow
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
Parts Name
RF Nut
RF Thrust Washer (white)
Pool Wall (for reference only)
RF Gasket (black)
Return Fitting (RF), threaded
RF Diverter
RF Locking Ring, threaded
Service Plug
Skimmer Seal Ring
Water Stopper
SFX Skimmer Strainer Basket
Skimmer Gasket Rubber Seal
Power Cord Set
Items Items
1
2
3
4
5
6
7
8
9
