VI. Deflation operation
（Figure 3）
（Figure 4）
VII. Precautions
* Remove the hose from the inflation inlet, and then connect it to the
deflation outlet instead (see Figure 3). Twist clockwise to tighten it.
* Connect the hose end with the air tap to your inflatable’s air inlet valve.
* Press the On/Off button to start the deflation. When the inflatable
is deflated, press the On/Off button to stop the deflation.
* Don't pull out the hose when inflating.
* Please note that the weather condition will affect the pump’s
performance pertaining to overheating. Instructions assume temperature
of up to 95F (35C).
* For maximum lifetime of the pump we suggest to have the pump rest
for 10 minutes after 30 minutes of continuous use.
* Applied power source must be the 12V DC car connector (as Figure 4).
* Do not block the inflation inlet (1) or deflation outlet (2).
OP20 DC12V ELECTRIC AIR PUMP
5
* If you are disposing of the pump observe the
local waste treatment regulation.
