10. PRODUCT CODE EXPLANATION
Item
Product Code
Description
① ② ③ ④ ⑤ ⑥ － ⑦ ⑧ ⑨ ⑩ ⑪ ⑫
Model Ｓ Ｕ １ ３ ０ ８ － Pulse Distributor
Power
６ 20 to 30VDC
７ 85 to 264VAC 50/60Hz
Flow Input
１ 8VDC 2-wire current pulse
２ Contact-closure pulse
３
2-wire voltage pulse and 12VDC 3-wire voltage
pulse
４ 24VDC 2-wire current pulse (4/20mADC)
５ 12VDC 2-wire current pulse
６ Open collector pulse
８ 32VDC 3-wire open collector pulse
９ Other than above
Output Pulse Width
１ Pulse width 1ms
２ Pulse width 50ms
３
Sync with input
Upper cuto󱐯 in width of pulses 10ms
４
Sync with input
Upper cuto󱐯 in width of pulses 100ms
５
Sync with input
Duty 1:1 output (Response 200Hz max.)
９ Other than above
０００ Always“000”
Allspecificationsaresubjecttochangewithoutnoticeforimprovement.
