PREPARATION
7
- Measure the thickness of your tiles on either side before installing the metal tracks. A thicker tile will
limit your space to install the shower panels.
- Make sure to have a distance tile to tile between 70 3/16 in (1783mm) Min and 70 13/16 in (1798mm)
Max (see image).
THIS SHOWER IS REVERSIBLE
This instruction is drawn up for an opening from right to the left (see illustration A).
For an installation from left to the right (see illustration B), use the same instructions, but switch
around the panels: mirror effect.
Make sure to have a distance (D) from the left
side tile to the right side tile:
D
Min: 70 3/16 in (1783 mm)
D
Max
: 70 13/16 in (1798 mm)
A
B
