©2009 Overhead Door Corporation Part Number 37027500123 02/26/2010 REV. 1
3
C
ODEDODGER
®
Access Security System
An electronic access code system that enhances the security of the door opener by continuously changing the access code each
time the remote control is used. The door opener responds to each new code only once. An access code copied from a working
system and tried again will not control the door opener.
OPENER FEATURES
Lighted Wall Button*
Operates door opener from inside garage. (Refer to section 3)
and Car2U
®
compatible.
Follow the Homelink
®
or Car2U
®
instructions in your car owner’s
manual.
TABLE OF CONTENTS
SECTION ......................................................................................PAGE
SAFETY INFORMATION .................................................................2
OPENER FEATURES .......................................................................... 3
SAFETY FEATURES ..........................................................................3
PRE-INSTALLATION CHECK LIST ...........................................4-5
RECOMMENDED TOOLS ...............................................................6
PARTS IDENTIFICATION ............................................................6-7
KEY ILLUSTRATIONS ......................................................................8
SAFETY INSTALLATION INFORMATION .................................9
INSTALLATION
1 OPENER ASSEMBLY ...........................................................9-10
2 INSTALLATION .................................................................11-13
3 WALL CONTROL INSTALLATION ..................................14-15
4 SAFE-T-BEAM
®
SYSTEM INSTALLATION .....................16-17
5 CONNECTING TO POWER ................................................... 18
ADJUSTMENTS
6 LIMIT SWITCHES & FORCE ADJUSTMENT ................. 19-20
CONTACT REVERSE TEST ...................................................... 20
7 PROGRAMMING REMOTE CONTROLS ............................. 21
8 BATTERY/VISOR CLIP INSTALLATION ............................... 22
9 LIGHT BULB AND LENS INSTALLATION ............................ 22
SAFETY INSTRUCTIONS ............................................................. 23
MAINTENANCE & TROUBLESHOOTING
10 ROUTINE MONTHLY MAINTENANCE ............................... 23
WIRING DIAGRAM ................................................................ 24
TROUBLESHOOTING GUIDE - OPENER ............................ 25
TROUBLESHOOTING GUIDE - POWER HEAD LED ........ 26
TRANSMITTER COMPLIANCE STATEMENT ....................... 27
WARRANTY ..................................................................................... 28
SAFETY FEATURES
Safe-T-Beam
®
Non-Contact Reversing System**
Puts an invisible beam across the door opening. The door stops
and reverses to the full open position if anything passes through
the beam. Red or green LED indicator lights on the power head
provide a self diagnostic code if an operational problem exists.
(Refer to Section 10)
Safe-T-Reverse® Contact Reversing System
Automatically stops and reverses a closing door within 2 seconds
of contact with an object. (Refer to Section 6)
Safe-T-Stop
®
Timed Reversed System
Automatically opens a closing door if it fails to close completely
within 30 seconds.
Watch Dog
™
Monitoring System
Monitors the Safe-T-Beam®** system to ensure proper functionality
and will automatically stop and reverse a closing door if a problem
is detected.
Automatic Lighting System
Two bulb lighting supplies up to 120 watts of light for safer
evening exits and entries. Turns ON when door is activated and
automatically turns OFF 3 minutes later.
Manual Emergency Release
Manually releases door from door opener. Use during a power
failure or other emergency to allow manual opening and closing of
door. (Refer to Section 6)
*OPENER MUST BE INSTALLED WITH THE INCLUDED
WALL CONTROL.
**SAFE-T-BEAM® SAFETY REVERSE SYSTEM MUST BE
INSTALLED TO CLOSE DOOR.
