The Front Panel
The front panel is where you can find the LED indicators. For information concerning
LED indicators, please refer to Chapter 5, LED Indicators.
Fig. 2-2 Front Panel
The Rear Panel
The rear panel is where you can locate the DC power jack, the 16 10/100Mbps station
ports and 1 Uplink port. For the technical specifications of the ports, please refer to
Product Specifications in Appendix A, Product Specification for detailed information.
Priority ports: port 5, 6, 7 and 8
Fig. 2-3 Front Panel
Station Ports (Port #1 to #16)
Live-FSH16T Fast Ethernet Switch is equipped with 16 10/100Mbps auto-sensing and
auto-negotiating ports. You can use these ports to connect to end stations, servers or other
networking devices.
DC Power Jack Station Ports
Station Ports
LED Indicators
