OWC ENVOY PRO EX User Manual

OWC Envoy Pro EX with USB-C Device Setup
3
6. Reseat the bottom cover onto the top portion of the
enclosure. Make sure the small cutout section where the
thermal pad is, rests above the PCIe connector, not the
drive mount screw.
If any edge or corner sits slightly
above the others remove the screws,
make sure the thermal pad is oriented
correctly and then re-ax the screws.
7. Using the two screws removed in Step 2, plus the two
remaining screws in the packet, secure the bottom cover
to the top portion of the device. The cover should sit
completely ush at the end of this process.
8. Last, take the two rubber feet, remove the adhesive
strip from each, and place each over the cutouts on the
bottom cover, as shown.
2.2 Usage Notes
- This device does not function with USB Type-A to Type-C cables or adapters
- With prolonged use, the drive case may be warm to the touch. This is normal.
For tips on formatting your new drive
please visit: www.owcdigital.com/support/formatting

OWC ENVOY PRO EX Specifications

General

NVMe	Yes
Interface	PCI Express 3.0
Read speed	1250 MB/s
Write speed	- MB/s
SSD capacity	8000 GB
SSD form factor	M.2
Wi-Fi	-
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector	USB Type-C
Data transfer rate	10 Gbit/s
Thunderbolt version	3
Certification	FCC
Product color	Silver
Housing material	Aluminum
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	115 mm
Width	65 mm
Height	9 mm
Weight	148 g
