OWC miniStack User Manual

OWC miniStack
Device Setup
7
5b. 2.5 inch SATA drive: Rotate the base as shown then
connect the SATA power and data cables to the
corresponding ports on the back of the drive. Set
the drive onto the black support strips, lining up the
screw holes.
6b. Hold the drive in place then ip the base over. Where
the screw holes on the drive overlap the screw holes
on the base, ax four the ne thread screws from
the packet.
7. Flip the base over then carefully align and re-seat the
top cover as shown at right.
8. Holding the top cover and base together, again ip
the miniStack over. Re-ax the four large corner
screws in the locations shown. Once complete, ip
the miniStack over.
This completes the assembly process.

OWC miniStack Specifications

General

HDD capacity	10000 GB
Storage drive size	3.5 \
Card reader integrated	No
Maximum storage capacity	10 TB
Installed storage drive type	HDD
Number of storage drives supported	1
Supported storage drive interfaces	Serial ATA III
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	2.5 A
AC adapter output voltage	12 V
Mac compatibility	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
USB connector gender	Female
Material	Aluminum
Product type	HDD enclosure
Certification	CE, FCC
Product color	Black, Silver
Number of fans	1 fan(s)
Chipset	ASMedia ASM1153E
Cables included	AC, USB
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 42 °C

Weight and Dimensions

Depth	197 mm
Height	36 mm
Weight	850 g
