OWIM HG07890A-MSF User Manual

9 GB/IE/NI
Mains adapter:
Information Value Unit
Manufacturer’s name or trade
mark, commercial registration
number and address
OWIM GmbH & Co. KG
HRA 721742
Stiftsbergstraße 1, 74167
Neckarsulm, GERMANY
Model identifier DM6308-BS-WH for
HG07890B-MSF
DM6308-BS-BL for
HG07890A-MSF
Input voltage 100–240 V∼
Input AC frequency 50 / 60 Hz
Output voltage 5.0 V
Output current 1.0 A
Output power 5.0 W
Average active efficiency 76.97 %
No-load power consumption 0.07 W
Protection class II
Outdoor sensor:
Temperature measurement range: -20 °C to +50 °C
-4.0 °F to + 122 °F
Humidity measurement range: 20 % to 95 %
Wireless range: max. 100 m (open area)
Batteries: 2 x LR06 (UM-3), 1.5 V
(size AA)
Protection class: IPX4
Frequency band: 433.050 MHz to 434.790 MHz
Transmitted maximum
radio-frequency power: 433.92 MHz, -10.77 dBm

OWIM HG07890A-MSF Specifications

General

Brand	OWIM
Model	HG07890A-MSF
Category	Weather Station
Language	English
