Owon PC341-W-TY - Device Ports and Controls; Port Identification and Reset Button

6
Reset Button
Power input po
21
For 2.5mm audio
Circuit CTs:
CIrcuit1
CIrcuit2
Antenna connector
For 3.5mm audio
Mains CTs:
Only for Cellular Version
L3/C
L2/B
L1/A
1. The 3.5mm L1/A, L2/B, and L3/C audio pos on the top of the main
unit are the inputs for the Main CTs.
All of the pos are labeled on the back of the main unit.
2. The 2.5mm audio pos on the sides of the main unit are the inputs
for the Sub CTs
3. The po on the bottom of the main unit are the inputs for power
cable
