4.Advanced User Guidebook
Choose the waveform to be saved. (If
certain channel is off, the corresponding
menu item will be disabled.)
(Choose All to save all the waveforms that
are turned on. You can save into the
current internal object address, or into USB
storage as a single file.)
Choose the address which the waveform is
saved to or recall from.
Recall or close the waveform stored in the
current object address. When the show is
ON, if the current object address has been
used, the stored waveform will be shown,
the address number and relevant
information will be displayed at the top left
of the screen; if the address is empty, it
will prompt "None is saved".
Close all the waveforms stored in the
object address.
Save the waveform of the source to the
selected address. Whatever the Type of
save menu is set, you can save the
waveform by just pressing the Copy panel
button in any user interface.
Select Type in the bottom menu, in the
right Format menu, you can select the
storage format.
Save to internal storage or USB storage.
When External is selected, save the
waveform according to the current record
length (see "Record Length menu" on P61);
the file name is editable. The BIN
waveform file could be open by waveform
analysis software (on the supplied CD).
When the type is Configure, the menu shows as following:
Save the current oscilloscope configure to
the internal storage
Recall the configure from the selected
address
When the type is Image, the menu shows as following:
To Next Page
