4. Under the status of stop, data comparing will stop, and when it goes on running,
the number of Pass/Fail will increase from the former number, not from zero.
5. When the waveform playback mode is on, Pass/Fail is used to test the
played-back waveform specially.
● Output
Push the Utility button, select Function in the bottom menu, select Output in the left
menu.
Output menu item in the bottom menu sets the output type of Trig Out(P/F) port in
Figure 3-3 Rear Panel on P6. In the bottom menu, select Output. The description of
Output menu is shown as the follows:
Video menu item in the bottom menu sets the output port of video. In the bottom
menu, select Video. The description of Video menu is shown as the follows:
Device and Print Setup menu items set the print output, refer to "How to Print the
Screen Image" on page 97.
● LAN Set
Using the LAN port or Wi-Fi, the oscilloscope can be connected with a computer. The
oscilloscope also supports communications with Android based smart device via
Wi-Fi. Refer to "Communication with PC" on page 115 and "Communication with
Android Device via Wi-Fi (Optional)" on page 123 for the operation steps.
● Update
Use the front-panel USB port to update your instrument firmware using a USB
memory device. Refer to "How to Update your Instrument Firmware" on page 84.
● DAQ
Turn off video output
Connect the VGA or AV port to an external monitor or
projector. Select the port in this menu, the oscilloscope
display can be shown on an external monitor or projector.
To Next Page
