OXO [T]Box RDM - General Instructions

User's Instruction
Page 5
General Instructions
10mm
DC INPUT:
9VDC, 500mA
MIDI IN
Under Voltage (Red)
Power (Green)
DMX IN DMX OUT
1=Ground; 2=Data-;3=Data+; 4=NC; 5=NC
1=Ground; 2=Data-; 3=Data+; 4= ; 5=5 Volt(Midi) Signal(Midi)
Physical Diagram
Displays the functions and guides you to operate the unit.
Used to operate this device
1. LCD :
2. Dial Wheel : .
It will light red when the unit is in the state of
"under voltage". It will light green when the
unit was supplied with the full power source .
Connects to the power of 9V DC, 500mA .
Used to input DMX signal via 5-pin or 3-pin
connector. To input MIDI via 5-pin connector.
Outputs DMX signal via 5-pin or 3-pin connector.
3. Power Indicator :
4. DC INPUT:
5. DMX/MIDI IN:
6. DMX OUT :
1
2
3
4
5 6
[T]Box-RDM
