DMX packet test
Turn the Dial wheel right to select and then press the Dial wheel to access
this function.
DMX packet test
< DMX packet test:
1. Data format >
2. Data timing >
3. Data level ( Volt ) >
If there is no signal input and you have accessed each menu of Data format, Data timing, Data
level ( Volt ) by the Dial wheel, the LCD window shows the same as follows:
< DMX packet test:
Receive no signal ?
You may locate the cursor to the label ? for help. In this case, the help message usually shows:
< DMX-512 tester help
No signal or signal
not complying with
USITT DMX-512( 1990 )
On the contrary, if there is signal input, you can do some DMX packet tests .
< Data format: ?
RX-Chan: 192
Break:--OK--
Signal present
Means the total
channels of Sirocco
1. Data format
Turn the Dial wheel to select and press it for viewing the total channels of external
operator and the states of BREAK when receiving the signals.
The LCD window shows the channel information of external connected DMX operator.
( For example, here the external connected DMX operator is Sirocco from us . )
Data format
User's Instruction
Page 7
[T]Box-RDM
