OXO [T]Box RDM - 1. Barchart Display

This DMX data--RX function can display the value of signal input by the means of Barchart and
Value and Min/max, complying with the display mode that can be adjusted in the System setup
menu.There are two display modes: Normal and Hold Mode.
In the display mode, when pushing the fader relative to the specific channel of external
operator ( e.g. Sirocco),therelative channel value of the LCD window will change
temporarily, conforming with the position of fader.
In the display mode, when pushing the fader relative to the specific channel of external
operator ( e.g. Sirocco),therelative channel value of the LCD window may not change
temporarily. The display value is only the max. value of all the adjustment by the fader.
Normal
Hold
< Data level
Reception may still
be possible with
lower level
<DMXdataRX
1. Barchart display >
2. Value display >
3. Min/ max display >
< RX Channel :000 ?
001: xxxxx xxxxx
011: xxxxx xxxxx
021: xxxxx xxxxx
Total channels of received
signal:000
Means: no signal input from
channel 1 to channel 10
For the further information, you may use the help function by pressing Dial wheel. The help
information shows as below.
For another menu available, you may turn the Dial wheel backward to return. Then select
the new entry by Dial wheel.
DMXdata--RX
Turn the Dial wheel forward to enter the Barchart display option. If there is no signal input,
the LCD window always show empty information as follows:
1. Barchart display
Turn the Dial wheel to select and then press the Dial wheel access this
menu function. There are 3 sub-menu options, including
DMX data--RX
Barchart display, Value display
and Min/max display.
User's Instruction
Page 9
[T]Box-RDM
